Key Specifications/Special Features:
• Image Device :1/4" CMOS or CCD
• Validity Pixel: P:720(H)×576(V); N:720(H)×480(V)
• Horizontal Resolution :420 TV Lines
• Video Output :1Vp-p 75ohms Negative
• Sync system: internal synchronization
• Gamma characterlstic: 0.45
• S/N ratio:<=48dB (AGC) off
• Cable: BNC jack
• Audio Output :Auto
• White Balance :Auto
• Minimum Illumination :1.0 Lux
• Electronic Shutter: Pal: 1/50~1/100,000s ; NTSC:1/60~1/100,000s ; CCIR: 1/50~1/100,000s ; EIA: :1/60~1/100,000s
• Built-In Lens : 2.8mm/3.6mm/6mm
• Power Consumption :12V /200 mA
• Operation Temperature :-10℃~+50℃
• Storage Temperature :-20℃~+60℃
• Water resistance: IP66
